I need Wire info...

[Paul]

im not sure how to read the wiring from the PDF..so Please just break it down for me...

I only want whats needed to make it run...no lights, oil pump, tors, light switch, ...ect...thanxs for all the help...and I did search the forum and only found one post with some of the info...and I have a 2k Blaster...thanxs for any help..



[stephen12091985]

the front light is yellow,green,black
the key switch is black with white strip,black ground



[Paul]

I dont want/need lights..I just need to know what needs to be hooked up to make the bike run...thats all!!!



[stephen12091985]

same thing if u take what doesnt need to be there u get the same thing



[Paul]

same thing if u take what doesnt need to be there u get the same thing

I think your missing what I am asking...








thats what I am working with...



[fioz600r]

I think your missing what I am asking...








thats what I am working with...

Little off topic here but I think your shocks are on upside down bro.

On topic here is a pic of the wireing diagram. For the stuff you dont to run anymore just delete those wires.



[blasterfreek30]

i think he means that he only needs the stator and cdi box to make a blaster run...thats it



[fioz600r]

i think he means that he only needs the stator and cdi box to make a blaster run...thats it

Dont you need more than that?:-/



[Paul]

HAHA...they are on up side down...Im telling you the guy I got the bike was didnt care after it had got stolen...this is how he got it back from the police....



[fioz600r]

here is a downloadable manual for you since my pics kinda suck LOL

http://www.blasterforum.com/general-support-17/downloadable-yamaha-blaster-manual-17325/

Hope it helps you out bro.



[The Ox]

For the most part, you willneed the wire going to the coil and cdi and then on either to the kill or key to shut it off (grounds it out)



[dlporkchop]

You only need the orange wire from cdi unit to coil and the black/white wire from the cdi unit. The b/w wire need to go to a kill switch,toggle switch,etc.. to be used as a cut off. The black wire from the cdi magneto also is a frame ground! I use a toggle switch with a pull tether kill switch for my blaster. The toggle keeps me from having to pull the tether every time I kill the motor.
